5.3 Feet Medium Duty Lathe Machine

Specification	Model No. PMD-80
LENGTH OF BED	5’3″ (1600 MM)
WIDTH OF BED	280 MM
HIGHT OF CENTER	9″ (228 MM)
SPINDLE BOR	52 MM
ADMIT BET. CENTER	850 MM
SWING OVER BED	425 MM
SWING OVER CROSS SLIDE	270 MM
SWING IN GAP	650 MM
LEAD SCREW DIA / THREAD	32 MM / 4 TPI
TAIL STOCK DIA/TAPPER	52 MM / MT-4
TAILSTOCK TRAVEL	150 MM
NO. OF SPINDLE SPEED	6/46 TO 570 RPM
WEIGHT APPROX.	700 KG
POWER REQUIRED	1.5 HP

‘PARTH MANUFACTURES’ Inception in 1998, has been dedicated to the manufacturing wide range of high-quality Heavy Duty, Medium Duty & Light Duty Lathe Machine under brand ‘PARTH’ Additional Information:

• Delivery Time: 10-15 DAYS
